| Test Parameters | Specification |
|---|---|
| Rated Voltage |
8 - 36 VDC |
| IP rating | IP 55 |
| Type of LED | SMD 3528 LED |
| Available Colours | Red |
| Operating Temperature | -40°C to 75°C |
| Storage Temperature | -40°C to 85°C |
| LVGP | NA |
| Hv Test for 60 sec. | 2KV |
| Material |
ABS |
| Screw Size for Wall Mounting | Screw Assembly |
| Rated Current | 1 AMP |
| Insulation Resistance | 1 m OHM |
| No Of LED | 1 |
| Switch Type | 1 NC |
| IP Protection | IP 55 |
| Mechanical Life | 100000 cycles |
| Electrical Life | 100000 cycles |
| Mounting | Screw Assembly |
| Voltage Drop in Contact | 30 mV |
| Change Over Force | 3 to 3.5 N |
| Symbol/Lable printing method | Pad printing |
| Contact material | Ag Ni |
| UV Resistance | PC-F1 as per UL 94 ABS-300 Hr as per UL 94 |
