| Test Parameters | Specification |
|---|---|
| Rated Voltage |
8-18 VDC |
| Function type | Push function |
| Contact type | NC |
| IP rating | IP 55 |
| Type of LED | SMD 3528 LED |
| Available Colours | Red |
| Operating Temperature | -40°C to 75°C |
| Storage Temperature | -40°C to 85°C |
| Hv Test for 60 sec. | 2 KV |
| Rated Current | 100mA |
| No Of LED | 01 |
| Mechanical Life | 100000 cycles |
| Electrical Life | 100000 cycles |
