ENTEGRAL FLUSH HEAD ALARM

FEATURES

Test Parameters	Specification
Safety
	Supply	IEC - 60947-5-1	UL-508	ITH/Thermal Current
Utilization Category	AC	AC-15	A600	10A
Utilization Category	DC	DC-13	P300
Contact	NO and NC
Rated Voltage	230V AC	120V AC	24V DC
Rated Current	6A	6A	1.5A
Frequency	50 - 60 Hz
Electrical Life for Contact / Warranty	1 Million Cycle/24 Months*
Rated Insulation Voltage	600 VAC
Terminals	Suitable for flexible or solid conductors from 2x1 mm2 to 2x2.5 mm²
Current Carrying Material	Brass
Contact Type	Make & Break
Contact Material	AgNi
Contact Resistance	20 MΩ
mV drop at 16 A DC	200 mV
Type	Non Illuminated / Illuminated
Function	Push, Push - Push, Push turn, Selector
Colour	Red / Green / Black / Yellow / White / Blue / Orange
Disposition of Contact
International Approvals	CE, UL
