| Test Parameters | Specification |
|---|---|
| Rated Voltage |
240V AC, 110V AC, 024V AC/ DC |
| Color Temperature | 2500°K - 6500°K based on requirement |
| CRI | Ra = 87 |
| Lumens | 248 |
| Over Voltage Protection | 340V (2 Hrs. working) |
| Surge Protection | 2 KV |
| Limit of Operating Voltage | -20% to +10% of rated voltage |
| Power Consumption | < 3 W +/- 0.5W |
| Operating Temperature | -30°C to 65°C |
| Storage Temperature | -30°C to 70°C |
Note:
***LED life is standard test condition.
*Lumens measured for all varient in standard test condition.
