| Test Parameters | Specification |
|---|---|
| Rated Voltage |
250V AC/DC |
| Minimum Applicable Load | 5V AC/DC, 1mA |
| Terminal Style | 110 solder/quick connect |
| Operating Humidity | 45 to 85% RH |
| Contact Resistance | 50M Ω maximum |
| Vibration Resistance | 10 to 55Hz, amplitude 1.2mm p-p |
| Contact Configuration | Single pole, double pole |
| Thermal Current | 5A |
| Storage Temperature | -25°C to +55°C |
| Degree of Protection | >10g |
| Insulation Resistance | 100M Ω minimum (500V DC megger) |
| Mechanical Life | Maintained : 1,000,000 operations minimum Momentary: 1,000,000 operations minimum Selector/Keylock : 250,000 operations minimum Switch unit : 2,000V AC, 1min between live/dead part and terminals of different poles; 1,000V AC, 1 minute between terminals of the |
| Electrical Life | 100,000 operations minimum (at full rated load) |
| Contact material | Gold-plated silver |
