Environmental Rating | |
---|---|
Operating Temperature | -25°C to 65°C |
Storage Temperature | -30°C to 70°C |
IP Rating | IP65 above panel (As per IEC/EN -60529) and NEMA 1,2,3,4,4X class 12 & 13 |
RoHS Compliance |
Yes |
Mechanical Life for Actuators | |
Momentary (Push Button with Push Function) | 1 million Operation |
Emergency Stop (Turn to Release) | 0.1 million Operation |
Emergency Stop (Push Pull Type) | 0.5 million Operation |
Selector | 0.5 million Operation |
