| Test Parameters | Specification |
|---|---|
| Rated Voltage |
240VAC, 24VAC/DC |
| SPL (Sound Pressure Level) | 90dB AT 1M |
| Input Power(W) | 1W |
| Surge Protection | 1KV |
| IP Protection | IP20 |
| Buzzer Sound Level | CONTINUOUS AND INTERMITTENT |
| Rated Current | 0.04A |
| Available Colours | RED, AMBER, YELLOW, GREEN, BLUE |
| Operating Temperature | -10°C ~ +65°C |
| Storage Temperature | -10°C ~ +65°C |
| HV Protection | 2KV BETWEEN BODY & CONTACT |
| LED State | CONTINUOUS AND BLINKING |
| Product Life | ? 1K HRS |
