Test Parameters | Specification |
---|---|
Product | Pro LED Indicator |
Rated Voltage |
12V AC/DC, |
Operating Voltage | -20% to +10% of rated voltage |
Type of LED | SMD LED's |
Available Colours | Red / Green / Blue / Yellow / Amber / White |
Life / Warranty | 0.5 Million burning hours/36 Months(At standard operating conditions) |
Operating Frequency | 50/60 Hz |
Operating Temperature | -25°C to 65°C |
Storage Temperature | -30°C to 70°C |
Wire Termination Capacity | 0.5 mm2, 1.5 mm2 - 2.5 mm2 |
LED Arrangement | Cluster Type |
Terminal Torque | 1 Nm |
Low Voltage Glow Protection | Available |
Surge Test | 2KV |
Hv Test for 60 sec. | 2.5KV |
Degree of Protection | Above Panel: IP65/ For Terminals: IP20 |
International Approvals | CE |
22.5mm Pro LED indicator lights are a type of industrial LED indicator that are used to provide visual feedback in a variety of applications. They are available in a variety of colors, sizes, and illumination levels, and can be used to indicate a wide range of conditions, such as power status, fault conditions, and operational status. Pro LED indicators are made with best-in-class technology and are designed to provide long-lasting performance. They are also universal/multi-voltage, which means that they can be used with a variety of power sources. In addition, they have inbuilt low voltage glow protection, which prevents them from being damaged by low voltage conditions.
These Panel Led indicators are made with SMD LED cluster technology, which provides them with a high level of brightness and reliability. They have also been subjected to a variety of reliability and life cycle tests, which ensures that they can withstand the harsh conditions of industrial environments.
There are many benefits to using High Quality 22.5mm Pro LED indicators, including:
High brightness: These LED indicators are made with SMD LED cluster technology, which provides them with a high level of brightness. This makes them ideal for use in applications where a high level of visibility is required, such as control panels and machinery.
Reliability: Pro LED indicators have been subjected to a variety of reliability and life cycle tests, which ensures that they can withstand the harsh conditions of industrial environments. This makes them a reliable choice for a variety of applications.
Wide range of options: These LED indicators are available in a variety of colors, sizes, and illumination levels. This allows you to choose the right indicator for your specific application.
Unparalleled Quality and Robust Design
Versatile Solutions for Every Application
Universal/Multi-Voltage Compatibility and Low Voltage Protection
SMD LED Cluster Technology for Superior Brightness
We are panel LED Indicators manufacturers and we understand the critical role that visual feedback plays in industrial settings. Whether it's monitoring power status, indicating fault conditions, or assessing operational status, having clear and reliable indicators is essential.
Therefore, our high quality 22.5mm Pro LED indicators are meticulously engineered to provide unmatched performance, ensuring optimal visibility and reliability in every application. We believe in Switch to Perfection!
